Description
Performance and Configuration Analysis Range 1ppm to 99.99%
Accuracy 0.1% （Au≥96%）
Sample Form Solid, powder, liquid
X-Ray Tube Voltage 5KV ~ 50KV
High Voltage Power Supply 0 ~ 50KV
X-Ray Tube Current 0μA ~ 1000μA
Camera HD camera
Filters Selectable customized switches
Detector Type proportional counter
Sample Chamber size 310 * 280 * 60 (mm)
Test Time 10sec ~ 100sec
Analysis Range Au, Ag, Pt, Pd, Cu
Analysis Software qualitative and quantitative
External Dimensions 400 * 430 * 350 (mm)
Weight 33Kg Instruments Environmental Requirements
Ambient Temperature -5 ° C ~ 40 ° C
Relative Humidity 15% ~ 90%
Power Requirements AC 110V OR 220V ± 5V, 50/ 60 Hz
No high power electromagnetic and vibration interference sources nearby
Within 30 second, you can get both the Karat value and content value of your gold sample.
Testing result of our comparable to the fire assay.
test will not destroy your gold sample.
Besides the gold, the non precious metals, such as Pt,Pd and Ag which are frequently used in the jewelries can also be simultaneously tested by our
